Description
Foot check valve constructed from high-quality brass alloy, offering reliable corrosion resistance and durability in water and general fluid systems.
Spring-loaded design ensures rapid valve closure to prevent backflow and protect pumps.
Equipped with a stainless steel mesh screen to filter debris and prevent clogging.
Rated PN10 for pressures up to 10 bar, suitable for low to medium-pressure applications.
Threaded ends provide secure, leak-tight connections and ease of installation.
Features
FEATURES / CHARACTERSTICS
Rating: PN10
Connections: BS EN 10226-1
BSPP Threaded(EX BS21)
Working Medium: Water, Oil and Steam.
Brass Body Lift Pattern Foot Valve,
Stainless Steel Mesh Threaded Ends
WORKING TEMPERATURE :
10 Bar -10° C to 100° C water
HYDROSTATIC TEST PRESSURE:
Shell- 15 bar
Seat- 11 bar
ON REQUEST :
NPT Threads (subject to minimum order quantities)
Specification
| Parts | Material |
|---|---|
|
Body |
Brass CW617N
|
|
Bonnet |
Brass CW617N
|
|
Disc |
Brass CW617N
|
|
Stem |
Brass CW617N
|
|
Rubber |
Nitrile Rubber |
|
Spring |
Stainless Steel 304 |
|
Mesh |
Stainless Steel 304
|
