Description
Vacuum breaker manufactured from high-quality brass alloy, offering reliable corrosion resistance for outdoor and potable water applications.
Designed to prevent back-siphonage and protect potable water supplies from contamination through hose connections.
Rated PN8.6, suitable for low-pressure systems up to 8.6 bar.
Compact and easy to install directly onto hose bibs or faucets for added system protection.
Features
FEATURES / CHARACTERSTICS
Rating: 125 psi (8.6 bar)
Brass Body,
DN15 x 3/4 thread,
Stainless Steel Spring & Screw
WORKING TEMPERATURE :
Max. Working Temperature: 180°F (82°C)
HYDROSTATIC TEST PRESSURE:
Max. Working Pressure:
125psi (8.6 bar)
ON REQUEST :
Chrome Finish (subject to minimum order quantities)
Specification
| Parts | Material |
|---|---|
|
Body |
Brass
|
|
Drain Assembly |
Thermoplastic
|
|
Diaphragm |
EPDM |
|
Sealing O-ring |
EPDM
|
|
Spring |
Stainless Steel
|
|
Screw |
Stainless Steel |
