Electric Actuators

Maplef MFNR.0.2-EQ
Supply voltage : 24V AC/DC ±15%, 50/60 Hz
Type : Electrical, bi-directional step motor
Power consumption : 24V AC: 6VA
24V DC: 4W
Inrush current : 1.8A (peak)
Control signal : Analog 0-10V DC
Resolution : 1:100
Feedback : No
Control mode : Equal %
Failsafe function : No
Manual override : Yes. 5 mm Allen Key
Position indicator : Yes
Operation time : 5.5 sec/mm
Actuating force : 200N (-30N/+70N)
Stroke : 1-8.5 mm / 0.04-0.33 in (auto adjusting)
Ambient temperature : 0°C to +50°C / +32°F to +122°F
Media temperature : 0°C to +120°C / +32°F to +248°F
Humidity rating : 0..80% rH, no condensation
Protection : IP54, class III, including upside-down, indoor use only
CE conformity : EN 60730
Cable : Fixed, 3 wires x 0.22 mm2, 1.5 meter
Fixed, 3 wires x AWG24, 4.9 ft
Closing point adjustment : During operation the actuator will self-adjust according
to the closing point and stroke length of the valve.

Maplef MFNR.0.3
Supply voltage : 110/230V AC ±10%, 50/60Hz
Type : Electrical, bi-direction step motor
Power consumption : 8VA
Control signal : Digital (2-position / 3-point floating)
Feedback : No
Failsafe function : No
Manual override : Yes. 5 mm Allen Key
Position indication : Yes
Operation time : 27.2 sec/mm
Actuating force : 200N (-30N/+70N)
Stroke : 1-8.5 mm / 0.04-0.33 in (auto adjusting)
Ambient temperature : 0°C to +50°C / +32°F to +122°F
Media temperature : 0°C to +120°C / +32°F to +248°F
Humidity rating : 0..80% rH, no condensation
Protection : IP54, class II, including upside-down, indoor use only
CE confomity : EN 60730
Cable : Fixed, 3 wires x 0.50mm2, 1.5 meter
Fixed, 3 wires x AWG20, 4.9 ft
Closing point adjustment : During operation the actuator will self-adjust
according to the closing points and stroke length of the valve.
