Description
“Robust Y-strainer manufactured from high-strength ductile iron, designed to protect pipelines and equipment by filtering out debris and contaminants.Flanged ends provide secure, leak-tight connections for easy installation and maintenance within pipeline systems.Suitable for medium-pressure applications, ensuring reliable performance in water, HVAC, and industrial processes.
Compact Y-pattern design allows efficient straining with minimal pressure drop and easy access to the strainer element for cleaning or replacement.”
Features
FEATURES / CHARACTERSTICS
Rating: 300 PSI
Connections: ANSI B16.1 Class 125
Applications: Fire protection, potable water, etc.
Bolted Bonnet, Y-Type Stainless Steel Screen,
Fusion bonded coating comply with AWWA
C550
WORKING TEMPERATURE :
32°F to 180°F (0°C to 82°C)
MAXIMUM OPERATING PRESSURE :
300 PSI (20.6 bar)
ON REQUEST :
Other Pressure Ratings (subject to minimum order quantities)
Specification
| Parts | Material | SPECIFICATION |
|---|---|---|
|
Body |
Ductile Iron |
A536 65-45-12 |
|
Cover |
Ductile Iron |
A536 65-45-12 |
|
Screen |
Stainless Steel |
AISI 304 |
|
Gasket |
EPDM |
|
|
Plug |
Carbon Steel |
